SUPPORT AND FAQ
If you have feedback, problems, or questions, we suggest you join our discord and chat with us directly or ask our community.
AEBOARDS STANDARDISED COMPONENTS
GASKETS:
If you want to use our gaskets, we usually have them in-stock or can be ordered for big orders. We currently use 1.5mm Poron, but have access to TPE, silicon and rubber. We have now standardised our sizing so that gaskets from Constellation, EXT65 V2 & Satellite are all compatible as well as our future models.
Note: These gaskets dimensions are slightly modified from the original EXT65 sizing.
FEET
Our feet are made of rubber with an adhesive top. We’ve designed these a bit thicker so there’s more contact on the desk and providing a more solid feel and experience. They are different to the later SCUF design, which is has thinner dimensions.
These feet are used in the AEBoard’s Constellation, Ivery’s Praxis, Z/T After/Noon and Abec13’s Adelie and all our collaboration and future models.
Sample Image | Download Step File
Specifications:
Width:51.5mm
Height: 9mm
Thickness: 2.5mm
Corner Radius: 4.5mm
Note: When adding feet holes to your model, please add an extra 0.25mm offset from these specifications, to account for rubber expansion and compression when in use
DESIGN FILES
LOGO FILES
RENDER FILES
You can use our files to render sets and colours on our boards. Don’t forget to let us know when you use it, so we can follow your projects!
AEBOARD COLOURS
Our boards come in 3 signature colours. We offer these throughout our product lines - feel free to use these colours, we would appreciate the use of “Aegis Navy” in reference to this colour, first seen on our OG keyboard - "the “Aegis”. We try to use the same colours but the anodisation process does have some variance between batches.
ADDITIONAL COLOURS
Treehouse Green
Influencer Red
FAQ
How can I change my layout or configure my PCB?
AEBoards keyboards have VIA compatability, allowing you to configure, test and design your keyboard. We highly recommend using it to tailor your needs.
Download at https://caniusevia.com/
AEGIS
I need the layout file for the AEGIS
Download the JSON file on GitHub
EXT65
(R1 PCB with the keyboard kit)
I have the EXT65 (R1 PCB) and my LED’s aren’t working
Flash this firmware to get it working
Video tutorial on how to flash firmware using QMK Toolbox
I need the layout file for the EXT65 (R1 PCB)
Download the JSON file on GitHub
TEXT
EXT65 R2 PCB
I have the EXT65 R2 PCB and it feels unresponsive
The EXT65 R2 PCB firmwre supports the OLED screen. If you do NOT have the OLED screen installed, it may feel unresponsive and laggy.
Flash this firmware to get it working
Video tutorial on how to flash firmware using QMK Toolbox
I need the layout file for the EXT65 R2 PCB
Download the JSON file
I bought the EXT65 R2 PCB and looking to cut my own case
Congratulations! We’re excited to help you bring your own EXT65 to life. Download som files here on GitHub, and feel free to edit them as you need.
Need help? Join the keyboard treehouse discord.
